Difference Between VAS 6154 and Vxdiag vcx nano 5054 ODIS Diagnose Interface

VAS 6154 is the newest vw diagnose interface for VAG Group.Multi-language VAS 6154 diagnose interface with wifi connection.Bellow OBD2repair.com tell you defference between ODIS diagnose VAS 6154 and Vxdiag vcx nano 5054 .



WIFI VAS 6154 ODIS VW 4.1.3 VAG Diagnose Interface

f:id:obd2repair01:20170815184954p:plain





VAS 6154 clone vs Vxdiag vcx nano 5054:

Vas6154 is a newer tool by VW which has replaced Vas5054a.Even newer ODIS 4.1.4 dropped support for vas5054a on win10.So eventually we won’t be able to use vas5054a anymore in future.Vas6154 is a newer designed head with wifi capability.



It looks like they have put their vxdiag vcx nano board inside a vas6154 case and calling it as a clone of newer Vas6154.



Actually NO. They’re different.

One side is similar. The other side vcx nano for VW/Audi is more complex. It could be firmware updated to support odis-S 4.1.3. I guess but if it does it may not be backward compatible with older odis-S (odis-E). Current firmware supports up to odis-S 4.1.3. Its API is old and it supports odis-E 6.6.1 but not sure of flash capability.



Vxdiag vcx nano 5054 inner board

f:id:obd2repair01:20170815184755p:plain



 f:id:obd2repair01:20170815185727p:plain

Cloned Vas 6154 ODIS Diagnose Interface Inner Board:



f:id:obd2repair01:20170815184832p:plain



It means they have improved the board based onvxdiag nano’s design, then make a new vas6154 with4 leds installed



Vxdiag vcxnano could not fit into OBD port of Audi, so you needed to buy an external cable extender, so they have changed shell to look like vas5054a/ vas6154 and made some other board features that can be only used with VW/Audi unlike vcx nano which can be used with many makes, if one purchases the license.



And I don’t think Vxdiag clones as original rather they use different design, which can work well for coding and calibrations but not firmware flash with odis engineering. VXdiag does not make enough tests. They have not managed to give information regarding flashing with O-E or giving out the info regarding which O-E is the compatible version. No youtube video no guidance.



I have vxdiag vcx nano wifi for VW and the board does not resemble with 5054a even though it is recognised as one. Flashing with odis engineering 6.7.5 failed causing instrument cluster failure.

Odis engineering 6.6.1 may work since all other functions work (tested and work) but I am afraid to check flashing capability since I don’t have a proper vas5054a as a back up. I am more interested in capability and internal chips quality rather than external appearance.



More detail about VAS 6154 ODIS diagnose interface, pls connect

Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163

Email: info@obd2repair.com
Facebook: www.facebook.com/obd2repaircom/

VCDS Interface V17.8.0 VAG COM VCDS V17.8.0 VAG Software Free Download



Ross Tech VCDS Kabel had new update to VCDS diagnose V17.8.0.VCDS interface VAG COM VCDS 17.8.0 with VAG Software 17.80 for more new vag group vehicle and support update online. OBD2repair.com share you VCDS Interface V17.8.0 VAG COM VCDS V17.8.0 VAG Software free download.


V17.8 VCDS Interface VAG COM VCDS V17.8.0 VAG Diagnose

f:id:obd2repair01:20170814153019p:plain



VCDS Interface VAG COM VCDS V17.8.0 VCDS Software V17.8.0 Download Free

http://bit.ly/2pZq3Zd



f:id:obd2repair01:20170814153203p:plain

New Vagcom VCDS Interface Functions:

00 Auto Scan

01 control module unit information

02 read fault codes

03 Output Test

       Selective output test (only for KWP-2000 *)

04 Basic settings

05 clear DTCs

06 Close Control Module

07 pairs of coding control module

       Slave control module for coding (only for KWP-2000 *)

Read measured value block 08

09-channel read (applies only to KWP-1281 *)

10 matching

11 Log (known under KWP-2000 * Coding II)

15 View Ready

16 security access (only for KWP-2000 *)

18 All supported fault codes (only for KWP-2000 *)

33 Common OBD-II function



More detail about VCDS Interface V17.8.0 VAG Diagnose Software,Pls connect

Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163
Email: info@obd2repair.com

How to Solve BMW Diagnostic Software BMW Rrheingold Ista Do not Read F-series

BMW Diagnostic Software BMW Rrheingold Ista is the software used togethere with bmw icom/ icom a2/icom next.OBD2repair.com share you solution of BMW Diagnostic Software BMW Rrheingold Ista Do not Read F-series following.
Problem:

Need help setting up BMW Rrheingold Ista software does not read F series

There is a diagnostic interface BMW ICOM  A2 + B + C, a Chinese clone.

Installed simply by installation, works fine reads scans, diagnoses, Version 3.47.10.13054

THERE IS A PROBLEM! Do not read the BMW F-series
Says it was not possible to identify the car.



What to do?

f:id:obd2repair01:20170807175755p:plain

f:id:obd2repair01:20170807175814p:plain

f:id:obd2repair01:20170807175841p:plain



BMW Rrheingold Ista Working solution:

Put in the VCI Configuration check box is not for the item “Prefer Ethernet as the preferred communication channel for ICOM.”



Test Result:

It works, thanks.



More detail about BMW Rrheingold Ista,pls connnect

Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163
Email: info@obd2repair.com

Lexia 3 pp2000 Peugeot Lexia Software Active Guide



Lexia 3 pp2000 Peugeot Lexia is the proffesional diagnostic interface for Peugeot and Citroen vehicles. Multi-language Lexia 3 pp2000 Peugeot Lexia PSA DiagBox diagnostics software allows you to perform a complete analysis of all models from 1995 to present.OBD2repair.com share you latest Lexia 3 pp2000 Peugeot Lexia  software free download and active guide:



2 PCB Lexia-3 921815C V48 Lexia3 PP2000 V25 PSA Diagbox 7.65 Full Chip

f:id:obd2repair01:20170807144207p:plain



Tested Lexia 3 pp2000 Peugeot Lexia Software Free Download:

http://bit.ly/2rPPr9v



Detail Steps of Lexia 3 pp2000 Peugeot Lexia Software Activation:



Follow pics until the 2nd last one, then add your details on this page to your keygen on the last page ,this will produce a code ,cut and paste this to the box in the 2nd last pic.
MANUAL ACTIVATION ONLY.

Click F5 with your mouse or press F5 on the keyboard.

how-to-activate-lexia-3-pp2000-1

Select Activation/Deactivation.

lexia-activation

Select Activation.

select-activation

how-to-activate-lexia-3-pp2000-4

Check your customer code and correct it if it is not correct. Then confirm to start activation.

how-to-activate-lexia-3-pp2000-5

Two ways to activate PP2000:

  1. by connecting to the Internet address:

https://www.wrs-actia.com/psa/ClientLogin

  1. by calling the hotline of your meiga representative.

In both cases above, you will be asked for the following information:

Your RRDI code, check whether the following code is correct: 001

The number of the version of your software packages: PP2000-23.43

The identifier of your PC: 4026979752

The server request code: 24188

From this information, you will be given an activation code.

Enter the code and then confirm to complete the activation.

how-to-activate-lexia-3-pp2000-6

how-to-activate-lexia-3-pp2000-7

Enjoy it !



More detail about peugeot lexia lexia 3 pp2000,pls connect

Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163
Email: info@obd2repair.com

Detail Steps about How to Update VCM II Ford Diagnostic Tool

VCM II Ford Diagnostic Tool  is OEM obd2 repair diagnostic tool with IDS software.For Ford VCM II with wireless function and support new and old vehicles.OBD2rpeair.com share you detail steps about how to udpate China clone VCM II Ford Diagnostic Tool



VCM II OEM For Ford IDS VCM II V105.01 with Flight Recorder Function

VCM II OEM For Ford IDS VCM II V105.01 with Flight Recorder Function



Detail Steps of How to update China Clone VCM II Ford Diagnostic Tool  Firmware?



Step 1. Press the power button on VCM2 scan tool main unit

Step 2. Long-press on the power button, connect VCM2 with power supply, wait for all 4 indicators turn on, then release the button

Step 3. connect VCM2 with computer via USB cable

Step 4. Run IDS software, software will prompt to update firmware

Step 5. Wait until the update procedure is done

Step 6. Restart computer when firmware update is completed

Step 7. Connect VCM2 kit with vehicle to start diagnosing or programming



More detail about VCM II Ford Diagnostic Tool ,pls connect

Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163
Email: info@obd2repair.com

How to Update Auto Code Reader Fcar F502 Heavy Duty Code Reader

Fcar F502 Heavy Duty Code Reader is 2017 new truck code reader for heavy-duty trucks (J1939 and J1708).Fcar F502 Heavy Duty Code Reader support ECU like CUMMINS/Bosch/DELPHI can be update online .OBD2repair.com share you how to update the AUTO code reader Fcar F502 Heavy Duty Code Reader.



Fcar F502 Heavy Duty Handheld Code Reader for J1939 and J1708 Truck Scanner



Fcar F502 Heavy Duty Code Reader F502 J1939 and J1708 Truck Code Reader





Fcar F502 Heavy Duty Code Reader Update Guide:



Step 1:Long-press “Enter” of Main Unit while insert it with USB cable.See Image 1

Step 2:Long-press “Enter” of Main Unitwhile insert it with USB cable. See Image 2.

Step 3:Long-press “Enter” of Main Unit while insert it with USB cable. See Image 3.

More detail about Fcar F502  Heavy Duty Code Reader,pls connect



Skype:obd2repair / eobdscan1
Whatsapp (+86)13728823163
Email: info@obd2repair.com

How to Solve BMW INPA BMW Scanner Error“ error vehicle not identified”

BMW Scanner BMW INPA cablw is the most proffessional diagnostic cable for BMW.BMW INPA Support full diagnostic of  all BMW with OBD1 20pin connectors as well as 16pin OBD2 Connectors. OBD2repair.com share you solution of BMW INPA BMW Scanner Error“ error vehicle not identified”



BMW INPA K+CAN Allows Full Diagnostic For BMW

INPA K+CAN Allows Full Diagnostic For BMW With FT232RL Chip



here are tracked back to m5board forum about BMW INPA following. Thanks to NAK91’s question and solutions.



"I recently installed ISTA+, INPA / EDIABAS and NCS and follow instructions from available resources online for establishing a connection with my 2008 E60 M5, but was met with the message:



The vehicle could not be identified. Please check the access to the vehicle and check whether testing-analysis-diagnosis has been activated



I’m fairly certain I followed the installation instructions properly, so my inclination is to believe that my problem could possibly be the cable. I honestly don’t remember where I got the cable. I got it probably 4-5 years ago and never got around to installing ISTA or DIS.

Would anyone be able to tell by looking at the BMW INPA cable? I’ve attached a picture of the cable that I have."



f:id:obd2repair01:20170802164710p:plain

So, this is the exact cable I bought awhile back on obd2repair.com

BMW INPA K+CAN Allows Full Diagnostic For BMW With FT232RL Chip



f:id:obd2repair01:20170802164645p:plain

Finally solved!!!

I had successfully reinstalled everything again and that I had tried establishing a connection with the vehicle using the BMW INPA cable and that it had failed (which it did).



However, I thought of something and decided to try it before posting that message. When I installed this time around, I noticed that there are TWO ediabas.ini files; one of them is in the EDIABAS directory under the system drive (C:\EDIABAS\Bin\ediabas.ini), along with the obd.ini, and the other is in the Rheingold directory (e.g C:\Rheingold\Ediabas\BIN\EDIABAS.ini, or wherever you unpacked Rheingold.7z).



I opened up the EDIABAS.INI in the Rheingold directory and changed the Interface = Remote to Interface = STD:OBD and then tried establishing a connection and it worked this time.



Unfortunately, the BEGINNERS GUIDE TO ISTA+ PDF only mentions the ediabas.ini file under the C:\EDIABAS directory:



So, for anyone who maybe hasn’t been able to establish a connection to their vehicle with BMW INPA cable  and has exhausted all of their options, this may be a good place to start.

Attached Thumbnails



f:id:obd2repair01:20170802160756p:plain

f:id:obd2repair01:20170802160811p:plain

    f:id:obd2repair01:20170802160718p:plain

Now, I need to perform a clutch adaptation.
